Google Workspace

Synapse integrates with Google Workspace (Gmail, Calendar, Drive, Docs, Sheets) via an OAuth-authenticated MCP server. Once connected, agents can read/write emails, create calendar events, manage Drive files, and more.

Setup

Step 1 — Create a Google Cloud OAuth app

1. Go to console.cloud.google.com and create a project
2. Enable the APIs you need:
   • Gmail API
   • Google Calendar API
   • Google Drive API
   • Google Docs API / Google Sheets API
3. Go to APIs & Services → Credentials → Create Credentials → OAuth 2.0 Client ID
4. Choose Web application
5. Add http://localhost:8000/api/mcp/oauth/callback to Authorised redirect URIs
6. Download the credentials JSON

Step 2 — Upload credentials to Synapse

Go to Settings → Google Workspace and upload the downloaded credentials JSON file.

Step 3 — Authenticate

Click Connect Google Account. A browser window opens for the Google OAuth flow. After authorising, the connection is confirmed.

Step 4 — Available tools

Once connected, Google Workspace tools become available to all agents:

Tool	Description
gmail_read	Read emails by label, search query, or ID
gmail_send	Send an email
gmail_reply	Reply to a thread
calendar_list	List upcoming events
calendar_create	Create a calendar event
drive_list	List Drive files
drive_read	Read a file's content
drive_upload	Upload a file to Drive
sheets_read	Read cells from a Google Sheet
sheets_write	Write data to a Sheet
docs_read	Read a Google Doc
docs_create	Create a new Doc

Example agent prompts

Check my calendar for tomorrow and send a summary to slack.

Read the latest 5 emails with subject "invoice" and extract the amounts into a spreadsheet.

Create a Google Doc with the draft report and share it with the team.

Token storage

OAuth tokens are stored in:

• DATA_DIR/token.json — main token
• DATA_DIR/google-credentials/token.json — workspace MCP token

Tokens are refreshed automatically. If the connection expires, go to Settings → Google Workspace and click Reconnect.

Required scopes

The OAuth app requests these scopes:

• https://www.googleapis.com/auth/gmail.modify
• https://www.googleapis.com/auth/calendar
• https://www.googleapis.com/auth/drive
• https://www.googleapis.com/auth/documents
• https://www.googleapis.com/auth/spreadsheets

You can restrict scopes in the Google Cloud console if you don't need all of them.
